The main components of the device UHP containers bound framework using advanced wire winding technology, the uniform stress distribution at work, compact structure, small size, long life. And ultra-high pressure vessel inner sleeve made of high strength stainless steel manufacturing, for pressurized water medium, corrosion-resistant ability meet the food, pharmaceutical processing industries. High degree of braking equipment, moving with the ends of the container lid opening and closing are electronically controlled hydraulic drive mechanism to complete. Moving parts in the fuel tank will promote a smooth and accurate implementation of the horizontal and vertical movement, to ensure accurate completion of each step, action-station. Electrical control system uses advanced Siemens programmable logic controller (PLC), WinCC monitoring, set up automatic and manual control mode, switch freely. equipment is simple, safe and reliable. Equipment Specifications: ModelBY.S-600/50LBY.S-600/100LBY.S-600/200LBY.S-600/250LBY.S-600/300LBY.S-600/400LBY.S-500/400L Maximum operating pressure600MPa600MPa600MPa600MPa600MPa600MPa400MPa Working mediumWaterWaterWaterWaterWaterWaterWater Container geometryInner diameter: ø220mm Length:1500mmInner diameter: ø260mm Length:2125mmInner diameter: ø300mm Length:3030mmInner diameter: ø300mm Length:3740mmInner diameter: ø320mm Length:3930mmInner diameter: ø360mm Length:4300mmInner diameter: ø400mm Length:4400mm Equipment size LWH4m×3m×2m （Plus long conveyor belt6m）5m×3m×2m （Plus long conveyor belt8m）5.5m×3m×2m （Plus long conveyor belt10m）6m×3m×2× （Plus long conveyor belt12m）6m×3m×2m （Plus long conveyor belt12m）6.5m×3m×2m （Plus long conveyor belt14m）7m×3m×2m （Plus long conveyor belt15m） Equipment weightAbout25TAbout33TAbout45TAbout55TAbout60TAbout80TAbout90T Pressurization time3-5Minute3-5Minute3-5Minute3-5Minute3-5Minute3-5Minute3-5Minute Power40KW80KW120KWW160KW160KW240KW240KW The company can be based on user requirements, design specifications and series of different combinations of parameters of horizontal and vertical high pressure food sterilization equipment to meet the requirements of different users
|
